Description
| Dimensions | |
|---|---|
| Max Working Height | 7.8m (25’7″) |
| Max Platform Height | 5.8m (19′) |
| Max Horizontal Extension | 0.9m (3′) |
| Length-Stowed | 1.8m (5’9″) |
| Width-Stowed | 0.81m (2’6.5″) |
| Height – stowed (Rail Folded) | 1.88m (6′) |
| Height – stowed (Rail Unfolded) | 2m (6’5″) |
| Wheelbase | 1.334m (4’3″) |
| Ground Clearance (Pothole Guard Stowed) | 75mm |
| Ground Clearance (Pothole Guard Deployed) | 25mm |
| Platform Dimensions(L×W×H) | 1.64m×0.76m×0.96m |
